Dual control via BLEDIM app or hand held remote
BLUETOOTH APP CONNECTION:
- Download app BLEDIM in the app store.
- DO NOT connect to the device in your phone settings menu
- Once connected you can adjust/create colors and patterns as well as turn on and off, the controller should retain the last used setting when powered off then back on.
RF HANDHELD REMOTE PAIR OR LOCK REMOTE: To pair the remote if connection lost or lock it so other remotes cannot control.
- Hold green power button.
- Remove fuse from controller for 5 seconds, place back in.
- Continue to hold green power button for 3 seconds
BRAKE/RED OVER RIDE: Connect blue wire to brake power wire, this will turn on red even if the lights are turned off and will override any current color if already on, we suggest placing on its own switch to only activate when you want it to.
COURTESY WHITE OVER RIDE: Connect white wire to switch or cortesy lights, this will turn on white even if the lights are turned off and will override any current color if already on.
*Additional instuctions can be downloaded*
